WI-TEK 8-Port Gigabit Unmanaged POE Switch WI-PS308G

WI-TEK Unmanaged Gigabit WI-PS308G switch with PoE (Power over Ethernet) function is designed for installation in modern high-speed networks of IP telephony, IP-video surveillance, and WiFi. When installing, configuring, and maintaining the switch, specialized knowledge is not required, which facilitates its use.

The switch is equipped with 8 ports 1000Base-T supporting the standard 802.3af / at (PoE, PoE +) 120 W and 2 ports 1000Base-T.

Features:

10 Port Gigabit Unmanaged Switch
8 – GB Port PoE { 10/100/1000 Mbps)
2 – GB Uplink Port { 10/100/1000 Mbps}
PoE Ports 1-8 Standard: 802.3 af/at
All 10 ports auto-MDI/MDIX
Data rates up to 2000Mbps
Plug and Play hassle-free installation

Interfaces	10 ports 10/100/1000M
Physical environments	10BASE-T: Category 3, 4, 5 UTP cable (max. 100m)
	100BASE-TX/1000Base-T: Category 5, 5e, 6 or higher UTP cable (max. 100m)
	1000Base-SX:62.5um/50um MMF（2m~550m)
	1000Base-LX:62.5µm/50µm MM（2m~550m) or 10µm SM (2m~5000m)
Cooling	passive
Power consumption	120W max. (with connected POE devices)
	Input voltage AC 110~240V 50/60Hz
Internal power supply

PoE ports (RJ45)	PoE ports 2 to 8 (802.3 af/at standard) up to 30W per port
PoE ports (RJ45)	PoE port 1 (802.3af/at/bt standard) up to 60W per port
Bandwidth	20Gbps
mac address table	4K
Dimensions	21015030mm
Temperature and Humidity	Operating temperature： -10℃～55℃
	Storage Temperature： -40℃～70℃
	Operating Humidity: 10%～90% RH non-condensing
	Storage humidity: 5%～90% RH non-condensing
Warranty	3 years
