PeopleLink iCam WHD 1080 12X USB_EN

PeopleLink iCam WHD 1080 are cameras for board rooms offering easy connectivity with laptops/PC through USB ports. The Pan/tilt features present in the devices allow a wider angle coverage . HD video quality with real time, face-to-face experience through the powerful 12x optical zoom some more unique offering of these cameras. They can also adjust the brightness automatically according to the lighting condition of the room ensuring clear video.

Rs. 175,500

Key Features

12x optical zoom : Optical zoom is a true zoom lens that produces much better-quality images than digital zoom which performs in-camera image processing
FOV 72.5 degree : The camera has a wide field of view (FOV), the area covered by the camera, of 72.5 degrees
IR remote controllable : Remotes with infrared light can be used to reliably control this camera
Pan tilt zoom: Pan-tilt-zoom (PTZ) type of cameras enable the user to control the movement and position of the lens. Panning refers to the lens’s horizontal movement while tilting describes its vertical movement
RS- 232: RS - 232 / VISCA to control the PTZ functions of the camera remotely
True HD 1080p @ 60 FP: This camera offers recordings with very vivid clarity (True HD) at a resolution of 1080p @ 60 frames per second (FPS)

General Features:

Sensor type: 1/2.7 CMOS sensor, 2.07 Megapixel Iris: Auto/Manual Resolution: 1080p/60, 1080p/50, 1080i/60, 1080i/50, 1080p/30, 1080p/25, 720p/60, 720p/50, 720p/30, 720p/25 Optical Zoom: 12x Effective Pixels: 2.07 Megapixel Pan Angle: -170° to +170° Tilt Angle: 6.9°/s Field of View: 72.5° Auto Focus: Auto/Manual Video Outputs: USB 3.0 Remote Control: Yes White Balance: Auto/Manual Exposure: Auto / Manual/SAE/AAE/Bright Pan Speed: 1.7° ~ 100°/s Tilt Speed: 1.7° ~ 69.9°/s Operating Temperature: -10° C ~ + 40° C Storage Temperature: -40° C ~ + 60° C Frames per Second: 60fps Illumination: 0.5 Lux @ (F1.8, AGC ON) S/N Ratio: >= 50 dB Dimensions: 128.5 x 118 x 156.2 mm Color: Gray,black Mount: Wall mount/Ceiling mount Cable: 3mtr USB 3.0 cable, Visca to RS232 control cable Presets: 128 Nos PTZ Control Protocol: Sony VISCA and PELCO P/D Gain Control: Auto Back-light Compensation: Auto/Manual Weight: 0.91 Kg Power: DC 12V, 1A Applications: boardrooms, center of learning, mission critical operation center, medical care units and court rooms Operating System Requirements: Windows® 7, Windows 8.1 or 10, Mac® OS X 10.10 or higher Compatibility: Universal USB compatibility

Image Sensor

Minimum Scene Illumination: 0.5 Lux @ (F1.8, AGC ON) Effective Pixel: 2.07 Megapixel Video S/N Ratio: >= 55 dB Color Compression: YUV 4:2:2 / H.264 / MJPEG Scanning Mode: Progressive Audio on USB: Support Exposure: Auto Electronic Shutter: Auto / Manual

Other Specifications

Video Output Port: USB 3.0 Video Format: 1080p/60, 1080p/50, 1080i/60, 1080i/50, 1080p/30, 1080p/25, 720p/60, 720p/50, 720p/30, 720p/25 Control port: RS232 / RS485 Communication Control Protocal: VISCA/PELCO Baud Rate: 9600 Preset Position: 128 Power Consumption: 12W OSD Menu: Access to OSD Menu and adjust camera module parameters Image Auto Flip: Support Horizontal / Vertical image flip Auto Pan Scan: Yes Environmental Humidity: 0-95% RH Remote Control: IR Wireless Remote controller P/T/Z Ports: 1 xUSB 3.0,1 x DC Power,1 x RS 232 RS232/RS485: Yes

Lens Presets 128 H & V Flip: Support Image Freeze: Support Preset Accuracy: 0.1°
