Peoplelink Epodium Ultra 200

PeopleLink ePodium Ultra delivers seamless interactivity among various digital devices with its ergonomic design which allows you to collaborate with your partners, customers, and business associates with technological ease; it provides great productivity benefits due to its modular form factor, achieving easy mobility of the device.



Area of application:

  • Classroom/Training room/Auditorium
  • Room Capacity: 60 to 80 seater

Rs.  468,000


Peoplelink Epodium Ultra 200

  • Body material
  • Body : Metallic
  • Top : Metallic
  • Top Sliding Mechanism: Yes
  • Provision for Monitor: Yes (up to 22 inches)
  • Electronic Monitor Lift: Yes
  • Document Camera Tray : Yes (Sliding Type)
  • RFID: Optional

Table Monitor Features

  • Screen Size : 21.5” wide LED
  • Resolution : 1920 x 1080
  • PC Connection : USB Port
  • Luminosity : 250 cd/m2
  • Input : HDMI
  • Number of Colours : 16.7M
  • Response time : 5ms Contrase ratio : 1000/1
  • Operating System : Windows, Linux, Mac.

Electrical

  • Input Voltage : DC 12V
  • Power : 100 – 250V AC : 100 – 250V AC.

Digital Signal Processor

  • Frequency Range : 30Hz -15000 Hz
  • Automatic Echo Cancellation : Yes
  • Automatic Gain Control : Yes
  • Dynamic Noise Reduction : Yes
  • Full Duplex : Yes
  • Line Input : 1x Line Input
  • Line Output : 1 x Line Output
  • USB Audio Port : 1 x USB Port

Package Includes

  • Microphone Options: 1 lapel + 1 Handheld
  • Frequencies Response: 50 Hz-18000 Hz
  • Antennas: 2 x 3dBi
  • Output: Balanced Out x2, Mixed Out x 1
  • Volume Control: Yes
  • Amplifier: Yes
  • Line Input: 1x Balanced, 2 x Unbalanced.
  • Phantom: Yes ( 15 V for Balanced Input)
  • Power output @8 ohms: 50 Watts x2
  • Minimum impedance: 8 Ohms
  • Frequency response : 20Hz-20000Hz
  • Speakers ( 1Pair): 50 Watts Speaker ( 1” Titanium Dome Tweeter, 5.25” Polypropylene Woofer, 90-20KHz Frequency response)

Central Controller

  • Ethernet : 1x RJ-45
  • RS-232 Port : Total 1 dedicated RS-232 Port
  • Relay Switch Port : Screen Up/Screen Down ( 2 Nos)

Control Pad

  • Type : Buttonpad
  • Interface : : RS-232
  • Power : 12V
  • Size : N/A
  • Type : Buttonpad with Buttons: VGA, HDMI, PC, Screen up/ Screen Down, Projector Lift up, Projector Lift Down, MicMute/Unmute, Volume Mute/Unmute, Volume Up/Down.

Laptop Interface

  • Type : Buttonpad
  • Interface : : RS-232
  • Power : 12V
  • Size : N/A
  • Type : Buttonpad with Buttons: VGA, HDMI, PC, Screen up/ Screen Down, Projector Lift up, Projector Lift Down, MicMute/Unmute, Volume Mute/Unmute, Volume Up/Down.
