Brand          HIKVISION

Spectrum value

image sensor 1/3" Progressive Scan CMOS

maximum resolution 4 Megapixel (2560x1440)

Main Stream Rate          20fps (2560x1440), 25fps (1920×1080, 1280×720)

Extra Stream Fee 25fps (1280x720, 640x480, 640x360)

Compression H.265+ / H.264+ / H.265 / H.264

Bitrate 32Kbps~8Mbps

Lens 2.8mm

Angle of View (FOV) H: 96°, V: 52°, D: 113°

DORI 64m (R), 25m (W), 12m (R), 6m (L)

minimum lighting          Color: 0.001 Lux @(F1.0, AGC ON)

0 Lux with white light range 30 m

Day Night ColorVu: Color image 24 hours

image enhancements WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror function, Privacy masking

Motion detection Motion Detection 2.0 with human and vehicle classification applied in motion detection.

Internal storage MicroSD card slot up to 256 GB

network interface Ethernet 10/100M BaseT

Remote access Web Browser, Hik-Connect Smartphone App, iVMS-4200 and Hik-Central PC Software

Interoperability ONVIF, ISAPI

Feeding DC 12 V / 400 mA / 5 W max. /PoE IEEE802.3af

Degree of protection IP67 waterproof

Material metal and plastic

Temp. functioning         -30ºC ~ +60ºC

Dimensions Ø 109.9 mm x 103.6 mm (H)

base dimensions Ø base 109.9 mm / Ø between screws 85 mm / 3 screws

Weight 380g
