Motion Detection 2.0

Human/Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;

Recording

• Video Compression H.265 Pro/H.265
• Encoding Resolution 1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA

Frame Rate

• Main stream: 1080p Lite/720p/720p Lite/WD1/4CIF@15 fps
• Note:

1080p Lite/720p is 15 fps by default

• Sub-stream: CIF/QVGA@15 fps
• Video Bitrate According to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.

Stream Type

• Video, Video & Audio

Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.

• Audio Compression G.711u

Audio Bitrate 64 Kbps

Video And Audio

• IP Video Input 2-ch Up to 5 MP resolution
• Support H.265+/H.265 IP cameras
• Analog Video Input 8-ch
• BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• HDTVI Input 1080p25, 1080p30, 720p25, 720p30
• AHD Input 1080p25, 1080p30, 720p25, 720p30
• HDCVI Input 1080p25, 1080p30, 720p25, 720p30
• CVBS Input Support
• HDMI Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• Video Output ModeHDMI/VGA simultaneous output
• Audio Input 8-ch via coaxial cable
• Audio Output 1-ch via HDMI
• Synchronous Playback 8-ch

Network

• Total Bandwidth 72 Mbps
• Incoming bandwidth: 8 Mbps
• Remote Connection 32
• Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
• Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
• Auxiliary Interface

Capacity

• Built-in 512 GB eSSD (480 GB available)

Note:

The device can store about 2 weeks videos for 8-ch analog cameras (default parameters), this estimation is for reference only.

• USB InterfaceRear panel: 2 × USB 2.0
• Alarm In/OutN/A

General

• Power Supply 12 VDC, 1 A
• Consumption≤ 6.2 W (with eSSD)
• Working Temperature-10 °C to 45 °C (14 °F to 113 °F)
• Working Humidity 10% to 90%
• Dimension (W × D × H)151 × 121 × 46 mm (5.94 × 4.76 × 1.81 inch)
• Weight≤ 0.5 kg (with eSSD, 1.1 lb.)
