Camera

• Image Sensor 1/2.4" Progressive Scan CMOS
• Max. Resolution 3200 × 1800
• Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
• Shutter Time 1/3 s to 1/100,000 s
• Day & Night IR cut filter
• Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Lens Type Fixed focal lens, 2.8, 4, and 6 mm optional

Focal Length & FOV

• 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°
• 4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°
• 6 mm, horizontal FOV 51°, vertical FOV 26°, diagonal FOV 59°

Lens Mount M12

Iris Type Fixed

Aperture F1.6

DORI

• 2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m
• 4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m
• 6 mm: D: 164 m, O: 65 m, R: 32 m, I: 16 m

Illuminator

Supplement Light Type IR

Supplement Light Range Up to 40 m

Smart Supplement Light Yes

IR Wavelength 850 nm

Video

Main Stream

• 50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• 60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream

• 50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360)
• 60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360)

Third Stream

• 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

*Third stream is supported under certain settings.

Video Compression

• Main stream: H.265/H.264/H.264+/H.265+
• Sub-stream: H.265/H.264/MJPEG
• Third stream: H.265/H.264

*Third stream is supported under certain settings.

Video Bit Rate 32 Kbps to 16 Mbps

H.264 Type Baseline Profile/Main Profile/High Profile

H.265 Type Main Profile

Bit Rate Control CBR/VBR

Scalable Video Coding (SVC) H.264 and H.265 encoding

Region Of Interest (ROI) 1 fixed region for main stream and sub-stream

Audio

Audio Compression -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Audio Bit Rate -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)

Audio Sampling Rate -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Environment Noise Filtering -U: Yes

Network

• Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
• Simultaneous Live View Up to 6 channels
• API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
• User/Host Up to 32 users. 3 user levels: administrator, operator and user
• Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
• Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

Client iVMS-4200, Hik-Connect, Hik-Central

Web Browser

• Plug-in required live view: IE 10, IE 11

• Plug-in free live view : Chrome 57.0+, Firefox 52.0+, Edge 89+
• Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+


Image Parameters Switch Yes

Image Settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Day/Night Switch Day, Night, Auto, Schedule

Wid e Dynamic Range (WDR) 120 dB

SNR≥ 52 dB

Image Enhancement BLC, HLC, 3D DNR

Privacy Mask 4 programmable polygon privacy masks

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage Built-in memory card slot, support microSD card, up to 512 GB

Built-In Microphone -U: Yes

Reset Key Yes

Event

Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception

Smart Event

• Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle))
• Face detection

Linkage Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email

General

Power

• 12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection,
• PoE: IEEE 802.3af, Class 3, max. 7.2 W

Dimension Ø70 mm × 161.7 mm (Ø2.8" × 6.4")

Package Dimension 216 mm × 121 mm × 118 mm (8.6" × 4.8" × 4.7")

Weight Approx. 485 g (1.1 lb.)

With Package Weight Approx. 744 g (1.6 lb.)

Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

General Function Heartbeat, mirror, heartbeat, password reset via email, pixel counter, anti-flicker

Language

• 33 languages
• English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Approval EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)

Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Protection IP67 (IEC 60529-2013)
