Camera

• Image Sensor1/3" Progressive Scan CMOS
• Max. Resolution2560 × 1440
• Min. IlluminationColor: 0.007 Lux @ (F1.6, AGC ON),0 Lux with light
• Shutter Time1/3 s to 1/100,000 s
• Day & NightIR cut filter
• Angle AdjustmentPan: -100° to 100°,tilt: -20° to 45°

  Lens

• Lens TypeVarifocal lens, motorized lens, 2.8 to 12 mm
• Focal Length & FOV2.8 to 12 mm, horizontal FOV 96.7° to 29.7°, vertical FOV 51.7° to 16.7°, diagonal FOV 114.3° to 34°
• Lens MountØ14
• Iris TypeFixed
• ApertureMax. F1.6

  DORI

• DORI

  Varifocal lens:
  Wide: D: 64 m, O: 25 m, R: 12 m, I: 6 m
  Tele: D: 200 m, O: 75 m, R: 40 m, I: 20 m

  Illuminator

• Supplement Light TypeIR
• Supplement Light RangeUp to 50 m
• Smart Supplement LightYes
• IR Wavelength850 nm

  Video

• Main Stream

  50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)
  60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
  60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264
  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 8 Mbps
• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 TypeMain Profile
• Bit Rate ControlCBR/VBR
• Region Of Interest (ROI)1 fixed region for main stream

  Audio

• Audio TypeMono sound
• Environment Noise FilteringYes
• Audio Sampling Rate8 kHz/16 kHz
• Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bit Rate64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

  Network

• SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,security audit log, TLS 1.2, host authentication (MAC address)
• Simultaneous Live ViewUp to 6 channels
• APIOpen Network Video Interface (Profile S, Profile G), ISAPI, SDK
• ProtocolsTCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, 802.1x, SMTP
• User/Host

  Up to 32 users
  3 levels: Administrator, Operator and User

• ClientiVMS-4200, Hik-Connect
• Web Browser

  Plug-in required live view: IE 10, IE 11
  Local service: Chrome 57.0+, Firefox 52.0+


• Wide Dynamic Range (WDR)120 dB WDR
• SNR≥ 52 dB
• Day/Night SwitchDay, Night, Auto, Schedule
• Image EnhancementBLC, HLC, 3D DNR
• Image SettingsMirror, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
• Privacy Mask4 regions of privacy mask

• Interface
• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage

  Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

• Built-In MicrophoneYes
• Reset KeyYes

  Event

• Basic EventMotion detection, video tampering alarm, exception
• LinkageUpload to FTP/memory card, notify surveillance center,send email, trigger recording, trigger capture

  General

• Power

  12 VDC ± 25%, 0.91 A, max. 11 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
  PoE: 802.3af, Class 3, 36 V to 57 V, 0.34 A to 0.21 A, max. 12.5 W

• MaterialFront cover: metal, body: plastic, bracket: plastic
• Dimension197.1 mm × 105 mm × 225.4 mm (7.8" × 4.1" × 8.9")
• Package Dimension300 mm × 266 mm × 172 mm (11.8" × 10.4" × 6.8")
• WeightApprox. 900 g (2 lb.)
• With Package WeightApprox. 1520 g (3.3 lb.)
• Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• LanguageEnglish, Ukrainian
• General FunctionAnti-flicker, heartbeat, password protection, password reset via e-mail

• Approval
• EMC

  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
  RCM: AS/NZS CISPR 32: 2015,
  IC: ICES-003: Issue 7,
  KC: KN32: 2015, KN35: 2015,FCC: 47 CFR Part 15, Subpart B

• Safety

  UL: UL 62368-1,
  CB: IEC 62368-1: 2014+A11,
  CE-LVD: EN 62368-1: 2014/A11: 2017,
  BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Environment

  CE-RoHS: 2011/65/EU,
  WEEE: 2012/19/EU,
  Reach: Regulation (EC) No 1907/2006

• ProtectionIP66: IEC 60529-2013
