Camera

Image Sensor 1/3″ Progressive Scan CMOS

Max. Resolution 2688 × 1520

Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on

Shutter Time 1/3 s to 1/100,000 s

Day & Night ICR Cut

Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Lens Type Fixed focal lens, 2.8, 4, and 6 mm optional

Focal Length & FOV

• 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122°
• 4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 100°
• 6 mm, horizontal FOV 52°, vertical FOV 28°, diagonal FOV 61°

Lens Mount M12

Iris Type Fixed

Aperture F1.6

DORI

• 2.8 mm: D: 67 m, O: 26 m, R: 13 m, I: 6 m
• 4 mm: D: 80 m, O: 31 m, R: 16 m, I: 8 m
• 6 mm: D: 120 m, O: 47 m, R: 24 m, I: 12 m

Illuminator

Supplement Light Type IR

Supplement Light Range

• -2I: up to 60 m
• -4I: up to 80 m

Smart Supplement Light Yes

IR Wavelength 850 nm

Video

Main Stream

• 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
• 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream

• 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
• 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Third Stream

• 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

Video Compression

• Main stream: H.265/H.264/H.264+/H.265+
• Sub-stream: H.265/H.264/MJPEG
• Third stream: H.265/H.264

Video Bit Rate 32 Kbps to 8 Mbps

H.264 Type Baseline Profile/Main Profile/High Profile

H.265 Type Main Profile

Bit Rate Control CBR/VBR

Scalable Video Coding (SVC) Yes

Region Of Interest (ROI) 1 fixed region for main stream and sub-stream

Network

Protocols  TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets

Simultaneous Live View Up to 6 channels

API Open Network Video Interface (Profile S, Profile G), ISAPI, SDK

User/Host Up to 32 users. 3 user levels: administrator, operator and user

Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Inter face

Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

Client iVMS-4200, Hik-Connect, Hik-Central

Web Browser

• Plug-in required live view: IE 10, IE 11
• Plug-in free live view : Chrome 57.0+, Firefox 52.0+
• Local service: Chrome 57.0+, Firefox 52.0+


Image Parameters Switch Yes

Image Settings Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Day/Night Switch Day, Night, Auto, Schedule

Wide Dynamic Range (WDR) 120 dB

SNR ≥ 52 dB

Image Enhancement BLC, HLC, 3D DNR

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage Built-in microSD, up to 512 GB

Reset Key Yes

Event

Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception

Smart Event

• Line crossing detection, intrusion detection
• Supports human and vehicle targets classification
• Face detection

Linkage Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, sned email

General

Power

-2I:

• 12 VDC ± 25%, 0.71 A, max. 8.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
• PoE: 802.3af, 36 V to 57 V, 0.27 A to 0.17 A, max. 9.5 W

-4I:

• 12 VDC ± 25%, 1.0 A, amx. 11.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
• PoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W

Material

• Aluminum alloy body
• Sun shield, IR cover: plastic

Dimension Ø105 × 299.7 mm (Ø4.1″ × 11.8″)

Package Dimension 386 × 156 × 155 mm (15.2" × 6.2" × 6.2")

Weight Approx. 1070 g (2.4 lb.)

With Package Weight Approx. 1589 g (3.5 lb.)

Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Language

• 33 languages
• English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function Anti-flicker, heartbeat, password reset via e-mail, pixel counter

Approval

EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)

Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Protection IP67 (IEC 60529-2013)
