Camera

Image Sensor 1/1.2" Progressive Scan CMOS

Max. Resolution 3840 × 2160

Min. Illumination Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light

Shutter Time 1/3 s to 1/100,000 s

Angle Adjustment Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Focal Length & FOV

• 2.8 mm: horizontal FOV102°, vertical FOV 52°, diagonal FOV 124°
• 4 mm: horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°
• 6 mm: horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°

Iris Type Fixed

Aperture F1.0

Depth Of Field

• 2.8 mm: 4.5 m to ∞
• 4 mm: 7 m to ∞
• 6 mm: 13 m to ∞

DORI

• 2.8 mm, D: 96 m, O: 38 m, R: 19 m, I: 10 m
• 4 mm, D: 102 m, O: 41 m, R: 21 m, I: 11 m
• 6 mm, D: 167 m, O: 66 m, R: 33 m, I: 16 m

Illuminator

Supplement Light Type White Light

Supplement Light Range 60 m

Smart Supplement Light Yes

Video

Main Stream

• 50 Hz: 25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)
• 60 Hz: 24 fps (3840 × 2160) 30 fps (3200 x 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream

• 50 Hz: 25 fps (640 × 480, 640 × 360)
• 60 Hz: 30 fps (640 × 480, 640 × 360)

Third Stream

• 50 Hz: 10 fps (1920 x 1080 , 1280 × 720, 640 × 480, 640 × 360)
• 60 Hz: 10 fps (1920 x 1080 , 1280 × 720, 640 × 480, 640 × 360)

Video Compression

• Main stream: H.265/H.264/H.264+/H.265+
• Sub-stream: H.265/H.264/MJPEG
• Third stream: H.265/H.264

Video Bit Rate 32 Kbps to 16 Mbps

H.264 Type Baseline Profile/Main Profile/High Profile

H.265 Type Main Profile

Bit Rate Control CBR/VBR

Scalable Video Coding (SVC) Yes

Region Of Interest (ROI) 1 fixed region for main stream and sub-stream

Network

• Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
• Simultaneous Live View Up to 6 channels
• API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
• User/Host Up to 32 users. 3 user levels: administrator, operator and user
• Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
• Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• Client iVMS-4200, Hik-Connect, Hik-Central

Web Browser

Plug-in required live view: IE 10, IE 11

Plug-in free live view : Chrome 57.0+, Firefox 52.0+

Local service: Chrome 57.0+, Firefox 52.0+


• Image Parameters Switch Yes
• Image Settings Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
• Day/Night Switch Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR) 130 dB

SNR ≥ 52 dB

Image Enhancement BLC, HLC, 3D DNR

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB

Reset Key Yes

Event

Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

Smart Event Line crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))

Scene change detection LinkageUpload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture, send email

Deep Learning Function

Face Capture Yes

General

Power

• 12 VDC ± 25%, 0.7 A, max. 8.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
• PoE: (802.3af, Class 3, 36 V to 57 V), 0.27 A to 0.17 A, max. 9.5 W

Dimension Ø105 × 289.5 mm (Ø4.1" × 11.4")

Package Dimension 385 × 190 × 180 mm (15.2" × 7.5" × 7.1")

Weight Approx. 1190 g (2.6 lb.)

With Package Weight Approx. 1700 g (3.7 lb.)

Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Language 33 languages : English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function Anti-flicker, heartbeat, password reset via e-mail, pixel counter

Approval

EMC

FCC (47 CFR Part 15, Subpart B);

CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);

RCM (AS/NZS CISPR 32: 2015);

IC (ICES-003: Issue 7)

Safety

• UL (UL 62368-1);
• CB (IEC 62368-1:2014+A11)
• CE-LVD (EN 62368-1:2014/A11:2017)

Environment

• CE-RoHS (2011/65/EU);
• WEEE (2012/19/EU);
• Reach (Regulation (EC) No 1907/2006)
• ProtectionIP67 (IEC 60529-2013)
