Camera

• Image Sensor 2 MP CMOS
• Signal System PAL/NTSC
• Resolution 1920 (H) × 1080 (V)
• Frame Rate
• TVI: 1080P@30fps, 1080P@25fps
• AHD: 1080P@30fps, 1080P@25fps
• CVI: 1080P@30fps, 1080P@25fps
• CVBS: PAL/NTSC
• Min. Illumination 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• ^ShutterTime PAL: 1/25 s to 1/50, 000 s
• NTSC: 1/30 s to 1/50, 000 s
• Lens 2.8 mm, 3.6 mm, 6 mm ĮdžĞĚ lens
• Field of View
• 2.8 mm, horizontal FOV: 106.4°, ǀĞƌƟĐĂů FOV: 57.9°, diagonal FOV: 124.6°
• 3.6 mm, horizontal FOV: 79.6°, ǀĞƌƟĐĂů FOV: 43.5°, diagonal FOV: 93.7°
• 6 mm, horizontal FOV: 51.9°, ǀĞƌƟĐĂů FOV: 30°, diagonal FOV: 58.8°
• Lens Mount M12
• Day & Night ICR
• WDR (Wide Dynamic Range) Digital WDR
• Audio Built-in mic
• Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 75°, ZŽƚĂƟŽn͗ 0 to 360°

Menu

• Image Mode STD/HIGH-SAT
• AGC Yes
• Day/Night Mode Auto/Color/BW (Black and White)
• White Balance Auto/Manual
• AE (Auto Exposure) Mode DWDR/BLC/HLC/Global
• Noise Reduction 2D DNR
• Language English
• Function Brightness, Sharpness, Mirror, Smart IR

Interface

• Video Output Switchable TVI/AHD/CVI/CVBS

General

• Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)
• Power Supply 12 VDC ± 25%
• Power Consumption Max. 2.7 W
• Material Plastic
• IR Range Up to 20 m

General

• Dimensions Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11")
• Weight Approx. 140.5 g (0.31 lb.)
