Hikvision 16-CH 1080P Lite Mini 1U H.265 DVR DS-7116HGHI-K1(C)(S)
Compression and Recording
• H.265 Pro+ video compression improves encoding efficiency and reduces data storage costs
• Full channel recording at up to 1080p lite resolution
Storage and Playback
• Smart search for efficient playback
Network & Ethernet Access
• Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
• 96 Mbps total bandwidth
Motion Detection 2.0
Human/Vehicle Analysis
- Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
- Quick search by object or event type is supported;
Recording
Video Compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution
- For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF
- For 720p stream access: 720p/WD1/4CIF/VGA/CIF
- For standard definition stream access: WD1/4CIF/VGA/CIF
Frame Rate
Main stream:
- For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps
- For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
- For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
Sub-stream:
- For 1080p and 720p stream access: CIF/QVGA@15 fps
- For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
Video Bitrate 32 Kbps to 4 Mbps
Stream Type Video, Video & Audio
Audio Compression G.711u
Audio Bitrate 64 Kbps
Video and Audio
IP Video Input
- 2-ch (up to 18-ch)
- Up to 5 MP resolution
- Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input
- 16-ch
- BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input 1080p25, 1080p30, 720p25, 720p30
- AHD Input 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input 1080p25, 1080p30, 720p25, 720p30
- CVBS Input Support
- HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode HDMI/VGA simultaneous output
Audio Input
- 1-ch RCA (2.0 Vp-p, 1 KΩ)
- 16-ch via coaxial cable
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio Reuse the first audio input
Synchronous playback 16-ch
Network
- Total Bandwidth 96 Mbps
- Network Protocol TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Remote Connection 128
- Network Interface 1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA 1 SATA interface
Capacity Up to 10 TB capacity for each disk
USB Interface Rear panel: 2 × USB 2.0
General
- Power Supply 12 VDC, 1.6 A
- Consumption ≤ 7 W (without HDD)
- Working Temperature -10 °C to 55 °C (14 °F to +31 °F)
- Working Humidity 10% to 90%
- Dimension (W × D × H) 285 × 210 × 45 mm (11.2 × 8.3 × 1.8 inch)
- Weight ≤ 1.8 kg (without HDD, 4.0 lb.)
